Principais características

• FishReveal ™
• Mapeamento em tempo real do Genesis
• Sonar com ajuste automático
• Transdutor HDI 83/200 com Med / High CHIRP e DownScan Imaging ™
• Mapa base mundial pré-carregado
• Monitor SolarMAX ™
• Novas paletas de cores para encontrar peixes
• Teclado otimizado com acesso com um toque aos principais recursos
• As opções de mapeamento incluem C-MAP, C-MAP Genesis, Navionics® e mais
• Slot para cartão microSD
• Montagem fácil no painel frontal ou no suporte do cardan
• Melhor desempenho do sonar em águas profundas

• Approvals

  Compliance	FCC, Industry Canada, Radio Equipment Directive, ACMA, RSM

  Display

  Backlight Color	Pure White LED
  Resolution	800 x 480
  Screen Brightness	>1000 NITS
  Size and Type	5″ (127 mm)SolarMAX Display
  Viewing Angles	80° top/bottom, 85° left/right

  Electrical

  Power Consumption, max.	0.9A @ 13VDC with backlight on full
  Power Consumption, min.	0.9A @ 13VDC with backlight on full
  Power Consumption, typical	0.9A @ 13VDC with backlight on full
  Recommended Fuse Rating	5A
  Supply Voltage	12v DC (10.8-17VDC)
  Humidity	60°C, 95% relative humidity (RH) for 18 hours

  Environment

  Operating Temperature Range	5°F to 131°F (-15°C to 55°C )
  Shock and Vibration	100,000 cycles of 20 G
  Storage Temperature Range	4°F to 140°F (-20°C to 60°C )
  Waterproof rating	IPX7 with card door closed

  GPS

  Correction	DGPS, WAAS
  Time to First Fix	30s

  MFD

  Cartography included	C-Map World Base Map
  Cartography supported	C-MAP Lake Insight HDC-MAP Insight ProC-MAP (MAX N, MAX N+)C-MAP GenesisGenesis LiveC-MAP Precision Contour HD (AMER ONLY)Navionics (Gold, NAV+ Platinum+)Insight (Pro and HD)Lowrance Regional Mapping Partners(No Photo/Satellite Overlay)
  External Storage	Micro SD Card(32 gb Max)
  GPS	1 Hz GPS GLONASS WAAS EGNOS MSAS
  Sonar (inc. compatibility)	Integrated: CHIRP Broadband DownScan
  Waypoints, Routes, Tracks	3000 Waypoints 100 Routes 100 Trails
  Compass Safe Distance – Metric, imperial	12″ (300mm)

  Physical

  Dimensions (W x H x D)	7.31″ (185.7 mm) x 4.32″ (109.8 mm) x 4.53″ (115.0 mm)
  Mounting Type	Gimbal Bracket Front Dash Flush Mount
  Weight	0.90 lb. (0.41 kg)

  Other

  Warranty Period	1 Year + 4 additional years ofupgrade options. Totaling 5 years
  Interface	Keypad: 8-way directional keypadZoom +/- Exit Enter/Menu Waypoint/Cursor Power/Light Pages
  Languages	Standard Language Pack: Afrikaans/Afrikaans, Danish/Dansk, German/Deutsch, English (US), English (UK), Spanish/Español, Finnish/Suomi, French/Français, Greek/Ελληνικά, Icelandic/íslenska, Italian/Italiano, Dutch/Nederlands, Norwegian/Norsk, Portugese (Brazil)/Português (BR), Portugese (Portugal)/Português (PT), Swedish/SvenskaAsian Language Pack: English (US), English (UK), Japanese/日本語, Korean/한국어, Thai/ภาษาไทย, Chinese – (simplified) China/简体中文, Chinese – (traditional) Taiwan/繁體中文Eastern European Language Pack:Bulgarian/Български, German/Deutsch, Estonian/Eesti, English (US), English (UK), Spanish/Español, French/Français, Hebrew/ عبری , Croatian/ Hrvatski, Hungarian/ Magyar, Italian/Italiano, Lithuanian/Lietuvos, Latvian/ Latvijas, Polish/Polski, Slovak/ Slovensky, Turkish/TürkçeRussia/Ukraine Language pack: German/Deutsch, English (US), English (UK), Spanish/Español, Italian/Italiano, Russian/Русский, Ukraine/ УкраїнськаMiddle Eastern Language Pack: Arabic (UAE)/ العربية , German/Deutsch, English (US), English (UK), Farsi/ فارسی , French/Français, Italian/Italiano
